Marstek Saturn B2500-D Plug-in Battery
€309.00
Available, delivery time: 2-5 Tage
Product information "Marstek Saturn B2500-D Plug-in Battery"
Plug-in battery with 2.24 kWh and two separate PV inputs for up to 1,600 W of module output. Compact enough for a balcony and commissioned without any work on the building's electrical installation.
Specifications
| Usable capacity | 2.24 kWh |
|---|---|
| Output power | 800 W (2 × 400 W) |
| PV input | 2 × 800 W, max. 1,600 W |
| Cell technology | LiFePO₄ (LFP) |
| Cycles | > 6,000 to 80 % remaining capacity |
| IP rating | IP65 |
| Dimensions | 309 × 175 × 350 mm |
| Weight | 20 kg ± 0.5 kg |
| Warranty | 10 years |
| Capacity: | Up to 2.5 kWh |
|---|---|
| Cell Technology: | LiFePO₄ (LFP) |
| IP Rating: | IP65 |
| Warranty: | 10 years |
